Introduction

Weighing and Bagging Machine can quantitatively weigh and package powders, granules and small blocks of materials, and is suitable for various packaging materials such as paper bags, aluminum foil bags, PE bags and composite material bags.

Application

image003(001)

Specification

Model	HY8-200	HY8-260	HY8-300	HY10-200
Pouch Width	W80-200mm	W140-260mm	W180-300mm	W100-200mm
Pouch Length	L100-400mm	L100-400mm	L100-400mm	L100-400mm
Capacity	25-60pouches/min	25-50pouches/min	10-35pouches/min	20-80pouches/min
Filling Range	10-1000g	10-1000g	10-2500g	10-1000g
Compress Air Requirement(supply by user)	≥0.6m³/min
Power	2.5kw	2.5kw	3kw	2.5kw
Dimension	L1890W1830H1430mm	L1890W1830H1430mm	L2290W1500H1420mm	L2090W1500H1420mm

Features

Intermittent Rotary Weighing System

This system employs an 8-10 station rotary intermittent operation mode. Each station independently completes weighing and filling. The weighing unit can be adjusted according to material density and bag type.

Automatic Detection and Fault Protection
Equipped with bag readiness detection and insufficient material detection devices, the filling and sealing modules stop operating when a bag is not in place or the filling material is insufficient, reducing packaging material waste.

Control and Operation Interface
The PLC control system combined with a touch screen allows for setting weighing formulas, adjusting filling volume and bag type parameters. The operation interface displays the status of each station and supports quick switching between multiple products.

Machine Materials and Cleaning
Parts in contact with materials are made of food-grade stainless steel. The machine body design facilitates disassembly and cleaning, meeting GMP hygiene standards.

Application industries

Food Industry

Suitable for packaging powdered, granular, and small-piece food products, such as candy, coffee powder, grains, seasonings, and freeze-dried foods. Supports single-bag quantitative weighing and filling.

Pharmaceutical and Health Products Industry

Suitable for packaging pharmaceutical powders, granules, and nutritional supplements. The weighing module can be adjusted according to dosage accuracy requirements, and the sealing module is suitable for standard pharmaceutical bags.

Chemical and Daily Chemical Industry

Suitable for packaging chemical granules, detergent powders, and small-piece chemicals. The filling volume is adjustable, the machine body material is chemically resistant, and the sealing temperature and pressure roller pressure can be set according to material characteristics.

Agriculture and Seed Industry

Suitable for packaging seeds, feed pellets, and fertilizer in small bags. The weighing module can be parameter-set according to bag type and material density, and the automatic detection function prevents misoperation.

Certificate

product-1400-328

FAQ

Q: What bag types and packaging materials does the equipment support?

A: It is suitable for paper bags, aluminum foil bags, PE bags, and composite material bags, supporting materials of different thicknesses and rigidities.

Q: How do I choose the appropriate model?

A: You can choose according to bag width, bag length, weighing range, and production capacity per minute. The number of rotating stations is adjustable (8 or 10 stations).

Q: How is weighing accuracy guaranteed?

A: Each station weighs independently. The bag must be fully opened before filling. The use of a material shortage detection device ensures that the weighing and filling correspond, reducing errors.

Q: Is daily cleaning and maintenance of the equipment complex?

A: The parts in contact with the material are removable for cleaning. Regularly checking the weighing module, filling device, and sealing rollers is sufficient to maintain normal operation.

Q: Can the equipment be connected to other systems?

A: It can be connected to powder, granule, or liquid filling systems to achieve fully automated packaging. Nitrogen purging, vacuum, metal detection, or checkweighing modules can be added to the interfaces.
